Escalators

Home/ Escalators

Escalators

Escalator Elevator Maintenance

VRSEPL specialize in design, manufacture, sales, installation and maintenance of Escalators, Autowalk and Travelators, Office Escalators, Electronic Escalators, Passenger Conveyor Escalators, Shopping mall Escalators these are mostly used in Shopping Malls, Restaurants, Big Complex Lobby area, Metro Stations, Airports etc, mostly these are installed for Indoor applications but can be customized for Outdoor applications too.


Escalator Elevator manufacturing

We are one of the most prominent manufacturers and Supplier of Escalator. The device consists of a motor-driven chain of individual, linked steps that move up or down on tracks, allowing the step treads to remain horizontal. Our escalators are available in varying capacities and speeds and can be customized for our clients at their discretion.


VRSEPL Commercial Escalator are made in compliance with the highest quality standards & appropriately designed to suit the specific customer requirements. Our escalators unique & aesthetic look with customized concept design enhances the overall look of the installed place & the building design.

Layout Diagram
VRS Car Parking System layout Diagram
Technical Specification
MODEL A B C D E
VRS30-600 600 838 1140 1200 18500
VRS30-800 800 1038 1340 1400 16900
VRS30-1000 1000 1238 1540 1600 15700
MODEL VRS30-600(4500People/hour) VRS35-800(6750People/hour) VRS35-1000(9000People/hour) Transport Size
Tavelling Height(mm) Net Height (KN) R1 R2 Motor Power(KN) Net Height (KN) R1 R2 Motor Power(KN) Net Height (KN) R1 R2 Motor Power(KN) H I
3000 54 43 39 5.5 56 49 44 5.5 60 56 50 5.5 2850 10180
3500 57 46 41 5.5 60 52 47 5.5 64 60 53 5.5 2890 11030
4000 60 49 41 5.5 63 56 50 5.5 67 64 57 7.5 2920 11890
4500 64 52 46 5.5 66 59 53 7.5 71 67 60 7.5 2940 12750
5000 67 54 49 5.5 70 62 56 7.5 74 71 64 11 2970 13610
5500 70 57 51 7.5 73 65 59 8 82 77 69 11 2980 14470
6000 73 60 54 7.5 76 69 61 11 85 81 72 11 3000 15330

If you have any questions about any product, please contact technical support by calling +91 93 20021995/ 93 21121996 or you can reach us by info@vrselevators.com anytime.
